 MIDNIGHT BLUE (CARBON) |
 OLIVE GREEN (CARBON) |
|
Add To Cart
 |
 |
 |
 |
|||||||||||||||||||||
| PRICE | $4,099 $2,899 USD |
$5,299 $3,699 USD |
$2,199 $1,499 USD |
|||||||||||||||||||||
| COLOR OPTIONS |
|
|
|
|||||||||||||||||||||
| FRAME | Scout Alloy 140mm | Scout Alloy 140mm | Scout Alloy 140mm | |||||||||||||||||||||
| WHEEL SIZE | 27.5" | 27.5" | 27.5" | |||||||||||||||||||||
| REAR SHOCK | Fox Float X Performance (205x57.5mm) |
Fox Float X Performance Elite (205x57.5mm) |
Fox Float X Performance Elite (205x57.5mm) |
|||||||||||||||||||||
| FORK | Fox Float 36 Rhythm (150mm) |
Fox Float 36 Grip 2 Performance Elite (150mm) |
||||||||||||||||||||||
| HEADSET | FSA No.57E | FSA No.57E | ||||||||||||||||||||||
| STEM | RaceFace Aeffect R (40mm) | ANVL Swage (40mm) | ||||||||||||||||||||||
| HANDLEBAR | RaceFace Chester 35 XS/SM(780x20) MD/LG(780x35) |
ANVL Mandrel Alloy 35 XS/SM(800x20) MD/LG(800x30) XL (800x 40) |
||||||||||||||||||||||
| GRIPS | ODI Elite Flow | ODI Elite Flow | ||||||||||||||||||||||
| SADDLE | ANVL Forge Cromo | ANVL Forge Cromo | ||||||||||||||||||||||
| SEATPOST | OneUp Dropper Post XS(120mm) SM(150mm) MD(180mm) LG(210mm) |
OneUp Dropper Post XS(120mm) SM(150mm) MD(180mm) LG(210mm) |
||||||||||||||||||||||
| BRAKES | SRAM Code R or SRAM Guide RE 4-Piston |
TRP DH-R Evo | ||||||||||||||||||||||
| ROTORS | SRAM Centerline (180mm) | TRP R1 2.3 (180mm) | ||||||||||||||||||||||
| SHIFTER | SRAM NX Eagle MMX | SRAM GX Eagle MMX | ||||||||||||||||||||||
| DERAILLEUR | SRAM NX Eagle | SRAM GX Eagle | ||||||||||||||||||||||
| CASSETTE | SRAM PG 1230 (11-50t) | SRAM XG 1275 (10-52t) | ||||||||||||||||||||||
| CHAIN | SRAM NX Eagle | SRAM GX Eagle | ||||||||||||||||||||||
| CRANK | SRAM Descendent 6k DUB (XS 32t/165mm) (SM/MD/LG 32t/170mm) |
SRAM GX Eagle DUB (XS 32t/165mm) (SM/MD/LG 32t/170mm) |
||||||||||||||||||||||
| RIMS | Stans Flow D | DT Swiss M 1900 Spline 30 | ||||||||||||||||||||||
| SPOKES | Pillar Double Butted | DT Swiss Champion | ||||||||||||||||||||||
| HUBS | Novatech D791SB/D902SB | DT Swiss 370 Ratchet LN | ||||||||||||||||||||||
| TIRE/FRONT | Maxxis Assegai 3C EXO+ (2.5) | Maxxis Assegai 3C EXO+ (2.5) | ||||||||||||||||||||||
| TIRE/REAR | Maxxis Minion DHRII 3C EXO+ (2.4) | Maxxis Minion DHRII 3C EXO+ (2.4) | ||||||||||||||||||||||
| INCLUDED | Tubeless Valves & Sealant | Tubeless Valves & Sealant | ||||||||||||||||||||||
| WEIGHT | 34.9 lbs / 15.83 kg (Size MD) | 33.4 lbs / 15.15 kg (Size MD) | 9.5 lbs / 4.31 kg (Size MD w/shock) | |||||||||||||||||||||
| Specs are subject to change at any time. All complete bikes are 95% assembled and packaged for quick and easy final assembly, and as such, Transition Bikes is not able to make special request build spec changes or modifications to packaging. | ||||||||||||||||||||||||
 |
|
Speed Balanced Geometry SBG ensures the bike maintains low speed agility, front wheel traction, and proper rider weight balance while actually increasing confidence in steep terrain and at high speeds. With SBG, a slacker head tube angle is combined with a reduced offset fork standard, preventing the front wheel from being too far in front of the rider. This improves front to rear weight distribution on the bike, which is often out of balance on long and slack bikes. One of SBG's greatest benefits is that it creates a confident steering feel that adapts to wheel speed. More stability when going fast, more agility on technical slow speed maneuvering as well as improved traction, control and confidence for any skill level of rider. |
||||||
|
XS | SM | MD | LG | XL | |
|
|
| ||||||
|
A. REACH | 410 | 435 | 460 | 485 | 510 | |
|
 |
||||||
|
B. STACK | 577 | 590 | 604 | 617 | 631 | |
|
|
||||||
|
C. EFFECTIVE TT LENGTH | 534 | 564 | 593 | 623 | 652 | |
|
|
||||||
|
D. SEAT TUBE LENGTH | 350 | 360 | 390 | 430 | 460 | |
|
|
||||||
|
E. EFFECTIVE ST ANGLE | 78.2° | 77.7° | 77.2° | 76.8° | 76.4° | |
|
|
||||||
|
SADDLE HEIGHT FOR EFFECTIVE ST ANGLE | 560 | 600 | 660 | 720 | 780 | |
|
|
||||||
|
ACTUAL ST ANGLE | 72° | 72° | 72° | 72° | 72° | |
|
|
||||||
|
SEAT TUBE OFFSET AT BB | 63 | 63 | 63 | 63 | 63 | |
|
|
||||||
|
F. HEAD TUBE LENGTH | 95 | 110 | 125 | 140 | 155 | |
|
|
||||||
|
G. HEAD TUBE ANGLE | 64.0° | 64.0° | 64.0° | 64.0° | 64.0° | |
|
|
||||||
|
H. CHAINSTAY LENGTH | 430 | 430 | 430 | 430 | 430 | |
|
|
||||||
|
I. WHEELBASE | 1153 | 1185 | 1217 | 1248 | 1280 | |
|
|
||||||
|
J. BOTTOM BRACKET DROP | 18 | 18 | 18 | 18 | 18 | |
|
|
||||||
|
K. ESTIMATED BB HEIGHT | 337 | 337 | 337 | 337 | 337 | |
|
|
||||||
|
L. STAND OVER HEIGHT | 665 | 665 | 673 | 686 | 698 | |
|
|
||||||
|
M. FORK OFFSET | 37 | 37 | 37 | 37 | 37 | |
|
|
||||||
|
|
||||||
| REAR TRAVEL: | 140mm (Compatible with 150mm) |
 |
|
| FRONT TRAVEL: | 150mm |
|
|
| WHEEL SIZE: | 27.5" |
|
|
| SIZES: | Carbon: XS, SM, MD, LG, XL Alloy: XS, SM, MD, LG |
|
|
| COLORS: | Carbon: Midnight Blue, Olive Green Alloy: Classy Black, Raspberry Red |
|
|
| FRAME BEARINGS: | 2x 6903, 2x 6902, 4x 6802, 2x 3802, 2x 6900 |
|
|
| FORK AXLE TO CROWN: | 545mm |
|
|
| FORK OFFSET: | 37mm |
|
|
| REAR SHOCK SIZE: | 205mm x 57.5mm (Compatible with a 205mm x 62.5mm shock) |
|
|
| SHOCK HARDWARE: | Trunnion Mount Top / 25mm x 8mm Bottom |
|
|
| HEADSET (TOP): | 44mm Zero Stack |
|
|
| HEADSET (BOTTOM): | 56mm Zero Stack |
|
|
| BB SHELL: | 73mm BSA Threaded |
|
|
| CHAINLINE: | 52mm |
|
|
| REAR BRAKE MOUNT: | 180mm Post Mount |
|
|
| REAR AXLE: | Carbon: Syntace X12 148, with a 1.0mm thread pitch Alloy: Transition Axle For UDH, 12mm x 148mm Spacing |
|
|
| ISCG TABS: | ISCG05 |
|
|
| SEATPOST DIAMETER: | 31.6mm |
|
|
| SEAT CLAMP: | Carbon: 37.0mm Alloy: 34.9mm |
|
|
| MAX SEATPOST INSERTION: | Carbon: XS 210mm | Small 220mm | Medium 250mm | Large 290mm | XL 320mm Alloy: XS 230mm | Small 240mm | Medium 270mm | Large 310mm |
|
|
| MAX CHAINRING SIZE: | 34T Single Ring |
|
|
| MAX TIRE SIZE: | 27.5 x 2.6 |
|
|
| REAR SHOCK SAG: | 140mm/57.5mm: 15-19mm (26-33%) 150mm/62.5mm: 16-20mm (26-32%) |
|
