PRICE | $8,999 $7,199 USD ![]() |
$9,999 $7,999 USD ![]() |
||||||||||||||
COLOR OPTIONS |
|
|
||||||||||||||
FRAME | Repeater Carbon 160mm | Repeater Carbon 160mm | ||||||||||||||
WHEEL SIZE | 29" | 29" | ||||||||||||||
DRIVE UNIT | Shimano DU-EP800 | Shimano DU-EP800 | ||||||||||||||
BATTERY | Shimano BT-E8036 (630Wh) | Shimano BT-E8036 (630Wh) | ||||||||||||||
DISPLAY | Shimano SC-EM800 | Shimano SC-EM800 | ||||||||||||||
ASSIST SWITCH | Shimano SW-EM800 | Shimano SW-EM800 | ||||||||||||||
REAR SHOCK | Fox Float X Performance Elite (205x65mm) |
Fox Float X2 Factory (205x65mm) |
||||||||||||||
FORK | Fox Float 38 Performance Elite (160mm, 1.5 Taper) |
Fox Float 38 Factory (160mm, 1.5 Taper) |
||||||||||||||
HEADSET | Acros ICR Alloy | Acros ICR Alloy | ||||||||||||||
STEM | ANVL Swage (40mm) | ANVL Swage (40mm) | ||||||||||||||
HANDLEBAR | ANVL Mandrel Alloy SM(800x20) MD/LG(800x30) XL(800x40) |
OneUp Carbon SM/MD(800x20) LG/XL(800x35) |
||||||||||||||
GRIPS | ODI Elite Flow Lock-On | ODI Elite Flow Lock-On | ||||||||||||||
SADDLE | SDG Bel Air V3 | SDG Bel Air V3 | ||||||||||||||
SEATPOST | OneUp Dropper Post SM(150mm) MD(180mm) LG/XL(210mm) |
OneUp Dropper Post SM(150mm) MD(180mm) LG/XL(210mm) |
||||||||||||||
BRAKES | TRP DH-R EVO | SRAM Code Silver Stealth | ||||||||||||||
ROTORS | TRP R1 2.3 (223/203mm) | SRAM HS2 (220/200mm) | ||||||||||||||
SHIFTER | SRAM GX AXS (Rocker Paddle) | SRAM POD Ultimate Bridge MMX | ||||||||||||||
DERAILLEUR | SRAM GX AXS | SRAM XO AXS Eagle Transmission | ||||||||||||||
CASSETTE | SRAM XG 1275 (10-52t) | SRAM XS 1295 T-Type (10-52t) | ||||||||||||||
CHAIN | SRAM GX Eagle | SRAM XO AXS | ||||||||||||||
CRANK | Shimano EM900 (160mm) | Shimano EM900 (160mm) | ||||||||||||||
CHAINRING | SRAM 34t Eagle Alloy E-Ring | SRAM XX 34t Steps Direct Mount | ||||||||||||||
CHAINGUIDE | OneUp STEPS | OneUp STEPS | ||||||||||||||
RIMS | RaceFace Aeffect R E-Bike | DT Swiss Hybrid HX 1700 | ||||||||||||||
SPOKES | RaceFace 2.0/1.7/2.0 | DT Swiss Hybrid 1 | ||||||||||||||
HUBS | RaceFace Trace 28h | DT Swiss Hybrid 350 | ||||||||||||||
TIRE/FRONT | Schwalbe Magic Mary, Super Gravity, Ultra Soft (2.4) | Schwalbe Magic Mary, Super Gravity, Ultra Soft (2.4) | ||||||||||||||
TIRE/REAR | Schwalbe Big Betty, Super Gravity, Soft (2.4) | Schwalbe Big Betty, Super Gravity, Soft (2.4) | ||||||||||||||
INCLUDED | Shimano EC-E6002 Charger Tubeless Valves & Sealant | Shimano EC-E6002 Charger Tubeless Valves & Sealant | ||||||||||||||
WEIGHT | TBD | TBD | ||||||||||||||
Specs are subject to change at any time. All complete bikes are 95% assembled and packaged for quick and easy final assembly, and as such, Transition Bikes is not able to make special request build spec changes or modifications to packaging. |
![]() |
![]() |
Speed Balanced Geometry ![]() SBG ensures the bike maintains low speed agility, front wheel traction, and proper rider weight balance while actually increasing confidence in steep terrain and at high speeds. With SBG, a slacker head tube angle is combined with a reduced offset fork standard, preventing the front wheel from being too far in front of the rider. This improves front to rear weight distribution on the bike, which is often out of balance on long and slack bikes. One of SBG's greatest benefits is that it creates a confident steering feel that adapts to wheel speed. More stability when going fast, more agility on technical slow speed maneuvering as well as improved traction, control and confidence for any skill level of rider. ![]() |
||||||
![]() |
SM | MD | LG | XL | ![]() |
||
![]() |
![]() |
||||||
![]() |
A. REACH | 425 | 455 | 480 | 510 | ||
![]() |
![]() |
||||||
![]() |
B. STACK | 631 | 631 | 640 | 649 | ||
![]() |
![]() |
||||||
![]() |
C. EFFECTIVE TT LENGTH | 559 | 589 | 617 | 650 | ||
![]() |
![]() |
||||||
![]() |
D. SEAT TUBE LENGTH | 375 | 400 | 440 | 470 | ||
![]() |
![]() |
||||||
![]() |
E. EFFECTIVE ST ANGLE | 78.4° | 77.9° | 77.4° | 77.1° | ||
![]() |
![]() |
||||||
![]() |
SADDLE HEIGHT FOR EFFECTIVE ST ANGLE | 600 | 660 | 720 | 780 | ||
![]() |
![]() |
||||||
![]() |
ACTUAL ST ANGLE | 72.5° | 72.5° | 72.5° | 72.5° | ||
![]() |
![]() |
||||||
![]() |
SEAT TUBE OFFSET AT BB | 65 | 65 | 65 | 65 | ||
![]() |
![]() |
||||||
![]() |
F. HEAD TUBE LENGTH | 110 | 110 | 120 | 130 | ||
![]() |
![]() |
||||||
![]() |
G. HEAD TUBE ANGLE | 64° | 64° | 64° | 64° | ||
![]() |
![]() |
||||||
![]() |
H. CHAINSTAY LENGTH | 455 | 455 | 455 | 455 | ||
![]() |
![]() |
||||||
![]() |
I. WHEELBASE | 1221 | 1251 | 1280 | 1315 | ||
![]() |
![]() |
||||||
![]() |
J. BOTTOM BRACKET DROP | 30 | 30 | 30 | 30 | ||
![]() |
![]() |
||||||
![]() |
K. ESTIMATED BB HEIGHT | 340 | 340 | 340 | 340 | ||
![]() |
![]() |
||||||
![]() |
L. STAND OVER HEIGHT | 705 | 715 | 720 | 725 | ||
![]() |
![]() |
||||||
![]() |
M. FORK OFFSET | 44 | 44 | 44 | 44 | ||
![]() |
![]() |
||||||
![]() |
![]() |
![]() |
![]() ![]() GIDDYUP SUSPENSION DESIGN ![]() We want to make it as easy as possible to experience great rear suspension performance. The GiddyUp suspension system is designed to behave intuitively across a broad range of setup. Because, we get it, sometimes you just want to grab your bike and GiddyUp, without checking your setup. When you do, it will always feel good. ![]() With nearly 26% progression and an E-bike specific version of our GiddyUp suspension kinematic, the Repeater has an excellent balance of support and small bump sensitivity. The Repeater suspension is tuned for maximum traction that enhances both descending and climbing experiences, while delivering a bottomless ride feel. A suggested sag range of 28 - 34% allows the rider to tune the feel of the bike; from a firm and snappy jump and slash mode, to a more supple and active full on party mode. Wherever you end up, you can focus on the trail without remotes, levers or knobs. Just grab your bike and GiddyUp. |
![]() |
![]() ![]() |
![]() ![]() ![]() |
![]() |
POWERED BY YOU, ASSISTED BY SHIMANO The Repeater comes equipped with a Shimano EP8 system that delivers 85Nm of torque, 250W continuous power and 500W peak power. All build levels come with Shimano's top of the line full color display, making it easy to tell which mode you are in with a quick glance. ![]() The EP8 motor comes pre-tuned by Transition with two profiles to maximize battery life and give you the best ride experience possible. Profile 1 is focused on giving you a powerful but natural ride feel in TRAIL mode, leaving BOOST for when you really need it, and making ECO more usable on the trail. Profile 2 is focused on range, helping you go as far as possible when distance is what you're after. Riders can easily modify the characteristics of ECO, TRAIL, and BOOST modes in both profiles via the Shimano E-Tube app. The Shimano EP8 system was designed specifically for offroad use, offering seamless integration, plenty of power, and options to customize the feel of the motor based on your preferences. |
![]() |
REAR TRAVEL: | 160mm | ||
![]() |
|||
FRONT TRAVEL: | 160mm | ||
![]() |
|||
WHEEL SIZE: | 29" | ||
![]() |
|||
SIZES: | SM, MD, LG, XL | ||
![]() |
|||
COLORS: | Mossy Green | ||
![]() |
|||
FRAME BEARINGS: | 2x 6903, 2x 6902, 4x 6802, 2x 6900 | ||
![]() |
|||
FORK AXLE TO CROWN: | 576mm | ||
![]() |
|||
FORK OFFSET: | 44mm | ||
![]() |
|||
REAR SHOCK SIZE: | 205mm x 65mm | ||
![]() |
|||
SHOCK HARDWARE: | Trunnion Mount Top / 25mm x 8mm Bottom | ||
![]() |
|||
HEADSET (TOP): | 56mm Zero Stack (For Internal Cable Routing) | ||
![]() |
|||
HEADSET (BOTTOM): | 66mm Zero Stack (Fits 1.5 or 1.8 Steerer) | ||
![]() |
|||
CHAINLINE: | 53mm | ||
![]() |
|||
REAR BRAKE MOUNT: | 180mm Post Mount, Max Rotor Size 223mm | ||
![]() |
|||
DERAILLEUR HANGER: | SRAM UDH | ||
![]() |
|||
REAR AXLE: | Transition Axle For UDH, 12mm x 148mm Spacing | ||
![]() |
|||
ISCG TABS: | Shimano STEPS Chain Guide Mount | ||
![]() |
|||
SEATPOST DIAMETER: | 31.6mm | ||
![]() |
|||
SEAT CLAMP: | 37.0mm | ![]() |
|
MAX SEATPOST INSERTION: | Small 225mm | Medium 250mm | Large 290mm | X-Large 320mm | ||
![]() |
|||
MAX CHAINRING SIZE: | 38 Tooth | ||
![]() |
|||
MAX TIRE SIZE: | 29 x 2.6 | ||
![]() |
![]() |
||
REAR SHOCK SAG: | 160mm/65mm: 18-22mm (28-34%) |
