Raw
Misty Green
|
$1,699 USD
$1,699
USD
Add To Cart
 |
|||||
| + More | |||||
| PRICE | $2,299 $1,699 USD |
||||
| FRAME | TR11 Alloy 200mm | ||||
| WHEEL SIZE | Mixed | ||||
| REAR SHOCK | Fox Float X Performance Elite (250x75mm) |
||||
| HEADSET | Transition Reach Adjust Included |
||||
| COLOR OPTIONS |
|
||||
| WEIGHT | 10.27 lbs / 4.7 kg (Size MD w/ Shock) | ||||
| Specs are subject to change at any time. All complete bikes are 95% assembled and packaged for quick and easy final assembly, and as such, Transition Bikes is not able to make special request build spec changes or modifications to packaging. |
 |
| REAR TRAVEL: | 200mm |
 |
|
| FRONT TRAVEL: | 200-203mm |
|
|
| WHEEL SIZE: | 29" Front / 27.5" Rear |
|
|
| SIZES: | SM, MD, LG, XL |
|
|
| FRAME BEARINGS: | 2x 6903, 4x 6902, 4x 6802 |
|
|
| FORK AXLE TO CROWN: | 606mm (Includes Headset) |
|
|
| FORK OFFSET: | 46-48mm |
|
|
| REAR SHOCK SIZE: | 250mm x 75mm Frame sizes small and medium are not compatible with the Fox Float X2 shock |
|
|
| SHOCK HARDWARE: | 25mm x 8mm Top and Bottom |
|
|
| HEADSET (TOP): | 56mm Zero Stack |
|
|
| HEADSET (BOTTOM): | 56mm Zero Stack |
|
|
| BB SHELL: | 83mm BSA Threaded |
|
|
| CHAINLINE: | 56.5mm |
|
|
| REAR BRAKE MOUNT: | 200mm Post Mount, 223 Max Rotor Size |
|
|
| REAR DERAILLEUR HANGER: | Transition TR11-HG |
|
|
| REAR AXLE: | Transition Axle For UDH, 12mm x 148mm Spacing |
|
|
| ISCG TABS: | ISCG05 |
|
|
| SEATPOST DIAMETER: | 31.6mm |
|
|
| SEAT CLAMP: | 37mm |
|
|
| MAX SEATPOST INSERTION: | 115mm |
|
|
| MAX CHAINRING SIZE: | 38T Single Ring |
|
|
| REAR MAX TIRE SIZE: | 27.5 x 2.5 (*see FAQ) |
|
|
| REAR SHOCK SAG: | 19-25mm (25-33%) | |
 |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
