The Sentinel was designed for 29er haters. A bike so capable, playful and fun that even the most staunch 29er naysayer will instantly convert. With our reverse mullet suspension configuration, the Sentinel stays responsive and playful while delivering incredible downhill monster truck capabilities. Our new Speed Balanced Geometry is our crown jewel that unlocks 100% of the potential of this bike. With SBG you get total confidence when it comes to cornering and climbing that really sets this bike apart from the crowd.

"The Sentinel is an absolute beast when it comes time to descend, a downright monster when the trail turns steep and rough. There are plenty of long-travel 29ers out there that can handle the Whistler Bike Park, but when it comes to tackling the steepest, chunkiest trails there aren't many that can match the Sentinel's performance." - Click here for the full review


Speed Balanced Geometry

SBG ensures the bike maintains low speed agility, front wheel traction, and proper rider weight balance while actually increasing confidence in steep terrain and at high speeds. With SBG, a slacker head tube angle is combined with a all new reduced offset fork standard, preventing the front wheel from being too far in front of the rider. This improves front to rear weight distribution on the bike, which is often out of balance on long and slack bikes. One of SBG's greatest benefits is that it creates a confident steering feel that adapts to wheel speed. More stability when going fast, more agility on technical slow speed manuevering as well as improved traction, control and confidence for any skill level of rider.


SM MD LG XL
REACH 425 450 475 500
STACK 617 617 626 635
EFFECTIVE TT LENGTH 568 593 622 650
SEAT TUBE LENGTH 360 400 440 490
EFFECTIVE ST ANGLE 77.5 76.8 76.3 75.8
HEAD TUBE LENGTH 100 100 110 120
HEAD TUBE ANGLE 64.0 64.0 64.0 64.0
CHAINSTAY LENGTH 435 435 435 435
WHEELBASE 1193 1218 1247 1277
BOTTOM BRACKET DROP 30 30 30 30
ESTIMATED BB HEIGHT 345 345 345 345
STAND OVER HEIGHT 685 695 700 715
FORK OFFSET 43 43 43 43



SPEC:  XO1   GX   NX   FRAME ONLY
COLOR:  TR BLUE   BLACK POWDER
PRICE:  $4,999

XO1 COMPLETE GX COMPLETE NX COMPLETE
  PRICE $4999 USD $3999 USD $2999 USD
  COLOR TR Blue, Black Powder TR Blue, Black Powder TR Blue, Black Powder
  REAR SHOCK Fox DPX2 Performance Elite Fox DPX2 Performance Elite RockShox Deluxe RT
  FORK Fox 36 Float RC2 Performance Elite 160mm RockShox Lyrik RC Solo Air 160mm RockShox Yari RC Solo Air 160mm
  HEADSET Cane Creek 40 Series FSA No.57E FSA No.57E
  STEM RaceFace Trubine R 35 (40mm) RaceFace Aeffect R (40mm) RaceFace Aeffect R (40mm)
  BAR RaceFace Turbine R 35 (800mm x 20mm) RaceFace Chester 35 (780mm x 20mm) RaceFace Chester 35 (780mm x 20mm)
  GRIPS ODI Elite Flow Velo Single Clamp Velo Single Clamp
  SADDLE ANVL Forge Stealth Cromo ANVL Forge Stealth Cromo WTB Volt Comp
  SEATPOST RockShox Reverb Stealth 1x Remote RockShox Reverb Stealth RaceFace Aeffect Dropper
  BRAKES SRAM Code RSC SRAM Code R SRAM Level T
  ROTORS SRAM Centerline (180mm) SRAM Centerline (180mm) SRAM Centerline (180mm)
  SHIFTER SRAM XO1 Eagle SRAM GX Eagle SRAM NX
  DERAILLEUR SRAM XO1 Eagle SRAM GX Eagle SRAM NX
  CASSETTE SRAM XG 1275 (10-50t) SRAM XG 1275 (10-50t) SRAM PG 1130 (11-42t)
  CHAIN SRAM GX Eagle SRAM GX Eagle SRAM PC 1110
  CRANK SRAM Descendent Carbon (30t, 170mm) SRAM Descendent 6K (30t, 170mm) RaceFace Aeffect (28t, 170mm)
  RIMS E*Thirteen TRS+ 30mm E*Thirteen TRS 30mm WTB STPi29
  HUBS E*Thirteen TRS+ Novatec D711SB & D462SB XD Novatec D711SB & D462SB
  TIRES Maxxis Minion DHF / DHR II 2.3 EXO 3C Maxxis Minion DHF / DHR II 2.3 EXO Dual Maxxis Minion DHF / DHR II 2.3 EXO Dual
FRAMESET
  PRICE $1999 USD
  COLOR TR Blue, Black Powder
  REAR SHOCK Fox DPX2 Performance Elite
FRAME & TECH INFO



FORK AXLE TO CROWN 571mm
FORK OFFSET 42mm (Rockshox) / 44mm (Fox)
REAR SHOCK SIZE 205mm x 57.5mm
REAR SHOCK HARDWARE Trunion Mount Top / 25mm x 8mm Bottom
HEADSET 44mm Zero Stack (Top) / 56mm Zero Stack (Bottom)
BOTTOM BRACKET 73mm BSA Threaded
REAR BRAKE 180mm Post Mount
REAR AXLE Syntace X12 148
FRONT DERAILLEUR No Support
ISCG TABS ISCG05
SEATPOST DIAMETER 31.6mm
MAXIMUM SEATPOST INSERTION Small 215mm, Medium 255mm, Large 295mm, XL 345mm
SEAT CLAMP 34.9mm
MAXIMUM CHAINRING 34t
MAXIMUM TIRE 29 x 2.5
SAG SETUP 18-20mm (32-35%)
WARRANTY 3 Year We Got Your Back Warranty
